F36 Highlights
-
Derived from Revel’s award-winning Performa3 Series Loudspeakers
-
6.5"deep anodized aluminum cone woofers
-
1" Aluminum Tweeter
-
Fourth generation Acoustic Lens waveguides
-
Computer optimized driver positioning and network integration
-
Constant Pressure Gradient Port Design
-
No visible fasteners on the front, top or side panels
-
Magnetic grilles with brushed metallic logos
General Specifications
| Crossover Frequencies | 600Hz, 1.8kHz |
|---|---|
| Enclosure Type | Bass-Reflex via Rear-Firing Port |
| High-frequency Driver Components | 1" Aluminum Tweeter with Acoustic Lens Waveguide |
| Nominal Impedance | 6 Ohms |
| Input Connections | Five-way binding posts |
| Low Frequency Extension | 51Hz, 45Hz, 33Hz |
| Low-frequency Driver Components | 3 x 6.5" Aluminum Cone Woofer |
| Recommended Amplifier Power | 30-200W |
| Sensitivity | 91dB (2.83V @ 1M) |
| Dimensions | 44.25" x 9.65"x 12.2" (112cm x 25cm x 31cm)—Including Feet |
| Weight | 50 lbs |
