C760 Highlights
General Specifications
Depth | 4.9" (12.5 cm) |
---|---|
Weight | 2.4 lb (1.1 kg) / Shipping weight 3.2 lb (1.5 kg) |
Features | Cutout dimensions (dia.) 8" (203.2 mm) • Includes both round and square zero-bezel magnetic grilles • Round grille finished dimension (dia.) 9.1" (23.1 cm) • Square grille finished dimensions (h x w) 9.1" x 9.1" (23.1 cm x 23.1 cm) |
High Frequency Driver Components | 1" aluminum dome swiveling high-output tweeter with waveguide |
Low Frequency Extension | High Frequency Extension (-10dB) 3-position HF level control Low Frequency Extension LF boundary compensation |
Low Frequency Driver Components | 6 ½" Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame High-Output Woofer |
Mounting | RollerLock tool-free installation mechanism • Compatible with wall material thickness range 0.5" – 1.0" (1.3 cm – 2.5 cm) |
Audio Specifications
Depth | 4.9" (12.5 cm) |
---|---|
Weight | 2.4 lb (1.1 kg) / Shipping weight 3.2 lb (1.5 kg) |
Features | Cutout dimensions (dia.) 8" (203.2 mm) • Includes both round and square zero-bezel magnetic grilles • Round grille finished dimension (dia.) 9.1" (23.1 cm) • Square grille finished dimensions (h x w) 9.1" x 9.1" (23.1 cm x 23.1 cm) |
High Frequency Driver Components | 1" aluminum dome swiveling high-output tweeter with waveguide |
Low Frequency Extension | High Frequency Extension (-10dB) 3-position HF level control Low Frequency Extension LF boundary compensation |
Low Frequency Driver Components | 6 ½" Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame High-Output Woofer |
Mounting | RollerLock tool-free installation mechanism • Compatible with wall material thickness range 0.5" – 1.0" (1.3 cm – 2.5 cm) |
