F35

F35WHAM

2 1/2-way Triple 5.25" Floorstanding Loudspeaker


The Concerta2 F35 floorstanding loudspeaker was designed to deliver outstanding accuracy over a remarkably wide frequency range. The 2 1/2-way triple 5.25” floorstanding loudspeaker has the ability to provide performance worthy of the most demanding entertainment systems.

Find a Dealer

F35

The F35 is a true full range 2 1/2-way 5.25” floorstanding loudspeaker that was designed to provide true high-end sound quality. It will deliver an impressive combination of wide frequency range, uncompressed dynamic range and low distortion across the entire audible spectrum.

High frequency response is supported by 1 inch aluminum dome tweeters that were derived from Revel’s Performa3 series. Low/Mid range frequency response is supported by 5.25” Aluminum cone woofers featuring low-distortion motor-structures for greater clarity and accuracy with improved sensitivity and output capability.

The patented wave guide design improves tweeter to woofer blend and significantly improves off-axis response for consistent performance over a wide listening area. In doing this we sacrificed no details by making sure no fasteners were visible allowing the speaker to show enhancing smooth lines of the cabinet and magnetically attached grilles. To finish the enclosure, we selected high gloss black and white finishes to highlight the features of this beautiful speaker.

  • Highlights & Specs
  • Documents & Downloads
  • Warranty

F35 Highlights

  • Derived from Revel’s award-winning Performa3 Series Loudspeakers
  • 5.25"deep anodized aluminum cone woofers
  • 1" Aluminum Tweeter
  • Fourth generation Acoustic Lens waveguides
  • Computer optimized driver positioning and network integration
  • Constant Pressure Gradient Port Design
  • No visible fasteners on the front, top or side panels
  • Magnetic grilles with brushed metallic logos

General Specifications

Crossover Frequencies 575Hz, 1.8kHz
Enclosure Type Bass-Reflex via Rear-Firing Port
High-frequency Driver Components 1" Aluminum Tweeter with Acoustic Lens Waveguide
Nominal Impedance 6 Ohms
Input Connections Five-way binding posts
Low Frequency Extension 55Hz, 46Hz, 35Hz (-3 dB, -6 dB, -10 dB)
Low-frequency Driver Components 3 x 5.25" Aluminum Cone Woofer
Recommended Amplifier Power 30-180W
Sensitivity 90dB (2.83V @ 1M)
Dimensions 40.25" x 8.42"x 12.2" (102cm x 21cm x 31cm)—Including Feet
Weight 41 lbs

Documents & Downloads

The latest owner's manuals, quick start guides, and documents.

Warranty 1 Year
